FEATURES
- Overhead v-valve
- 90° V-twin
- High performance pressurized lubrication
- Electronic spark ignition
- Automatic compression release
- Internally vented carburetor
- Rotating grass screen
- Dual stage canister air filter
- Cast-iron cylinder liners
- Metal engine cover
Specifications
- Displacement 852 cc (52.0 cu. in.)
- Number of Cylinders 2
- Bore x Stroke 3.33 x 2.99 in. (84.5 x 76mm)
- Compression Ratio 8.2:1
- Oil capacity w/filter 2.5 U.S. qt ( 2.4 liters)
- Maximum Power 25.5 hp (19.0 kW)at 3,600 RPM
- Maximum Torque 44.6 ft lbs (60.5 N·m)at 2,400 RPM
- Dry Weight 124.0 lbs (56.4 kgs)
- Note :- Muffler not supplied with engine
